Victaulic® V080761SE3 Vic-300 MasterSeal™ 761 Butterfly Valve, 8 in Nominal
Victaulic® V080761SE3 Vic-300 MasterSeal™ 761 Butterfly Valve, 8 in Nominal, -30 to 250 deg F, 5.33 in Inlet to Outlet Length, 8.625 in OD x 16.63 in H, 416 Stainless Steel (Stem) Stem & Pin Material, Grooved, Media: Water, Gear Actuator, 11.56 in Top to Inlet Center, Ductile Iron Body, Ductile Iron Disc, Alkyd Enamel Coated, Black Oxide, Series: 761
Electroless nickel coated ductile iron disc Seat patented pressure enhanced rubber seat design Drive hub designed to accept nearly all types of actuation Stem seals prevents leakage of media Upper and lower stem bearings helps maintain constant low torque values for the life of the valve Stem blow-out proof design utilizing stainless steel Grooved end body reduces the weight of the valve and makes it easier to install Seal cartridge patented seal cartridge houses stem seals Thermal barrier reduces condensation on gear operators when installed in chilled water applications Body - Ductile iron conforming to ASTM A-536, grade 65-45-12 End face, 2 to 6 in ductile iron conforming to ASTM A-536, grade 65-45-12 Grade E green color code EPDM seat Designed for bi-directional, dead end services to full working pressure Carbon steel stem retaining ring Fiberglass or 316 stainless steel with TFE lining bearing Standard C36000 brass stem seal cartridge
