CRESLINE® 47745
CRESLINE® Pressure Pipe, 10 in Nominal, Belled, 10.02 in Inside Dia, 10-3/4 in Outside Dia, 20 ft Length, 0.365 in Wall Thickness, SCH 40/STD, 140 psi Working, PVC, ASTM D1785, NSF Approved
4 in expansion or contraction per 1000 ft per 10 deg F temperature change 1.41 specific gravity 7000 psi tensile strength 115 R-scale hardness 450 V/mil dielectric strength 140 psi at 73.4 deg F 7.5 in D socket Pressure rating is the estimated maximum pressure that water as the medium in the pipe can exert continuously with a high degree of certainty that failure of the pipe will not occur
